SS 410 Plates

Design Standards: ASTM A240, ASME SA240, EN 10088-2

Material Grade: Stainless Steel 410 (UNS S41100)

Alloy Category: Martensitic (Heat-Treatable) Stainless Steel

Hardness Range: Adjustable via Quenching and Tempering

Thickness Range: 0.5 mm to 80 mm

Surface Finish: 2B, No.1 (HRAP), BA, Polished

Process Capabilities: Precision Machining, Hardening, Grinding

Key Applications: Valve Parts, Pump Shafts, Cutlery, Fasteners

goldenislands.com.sa

SS 410 Plates are the basic martensitic stainless steel plates designed to provide high mechanical properties, specifically hardness and strength, through heat treatment. Unlike austenitic grades, Grade 410 is a 12% chromium steel that can be hardened by quenching and tempering, making it the ideal choice for applications requiring high wear resistance and moderate corrosion resistance. These plates offer excellent stress-corrosion cracking resistance and are frequently utilized in environments where high strength and resistance to scaling at elevated temperatures are essential.

Manufactured to ASTM A240 and ASME SA240 standards, SS 410 plates perform exceptionally well in mildly corrosive environments, such as those found in steam and gas turbine components, petroleum refining, and power generation. In the annealed condition, the material is ductile and can be easily formed or machined, but it achieves its maximum corrosion resistance only after being hardened and polished. Whether used for valve parts, pump shafts, or industrial fasteners, our SS 410 plates provide a cost-effective, high-strength solution with reliable performance up to temperatures of 650°C.

SS 410 Plates Features

» Heat-Treatable Strength: As a martensitic grade, it can be hardened by quenching and tempering to achieve high levels of tensile strength and hardness tailored to specific industrial needs.
» High Wear Resistance: Offers superior resistance to abrasion and mechanical wear compared to austenitic grades, making it ideal for moving parts and abrasive environments.
» Good Corrosion Resistance: Provides effective resistance to atmospheric corrosion, potable water, and mildly corrosive chemicals, especially when the surface is hardened and polished.
» Thermal Stability: Maintains excellent resistance to scaling and oxidation in continuous service at temperatures up to 650°C (1200°F).
» Excellent Machinability: In the annealed condition, SS 410 is easily machined, allowing for the fabrication of complex components like valve stems and pump shafts.
» Magnetic Properties: Inherently magnetic in both the annealed and hardened conditions, which is beneficial for applications requiring magnetic attraction or separation.
» Stress Corrosion Resistance: Exhibits high resistance to stress-corrosion cracking when hardened to appropriate levels, essential for high-stress industrial applications.
» Cost-Effective Alloy: Provides a high-strength, stainless solution at a lower cost than high-nickel alloys, offering great value for utility-based industrial projects.

SS 410 Plates Specification

Standard Specs

ASTM: A240 / A240M
ASME: SA240 / SA240M
UNS Number: S41000
Werkstoff No: 1.4006

Chemical Profile

Chromium (Cr): 11.5% – 13.5%
Manganese (Mn): 1.0% Max
Silicon (Si): 1.0% Max
Carbon (C): 0.08% – 0.15%

Mechanical Data

Tensile Strength: 450 MPa (Min)
Yield Strength: 205 MPa (Min)
Elongation: 20% (Min)
Hardness: 217 Brinell Max (Annealed)

Size Range

Thickness: 0.5mm to 80mm
Width: 1000mm / 1250mm / 1500mm
Length: 2000mm to 6000mm
Forms: Plates, Sheets, Strips

Physical Data

Density: 7.75 g/cm³
Magnetic: Ferromagnetic (All conditions)
Melting Point: 1480°C – 1530°C
Elastic Modulus: 200 GPa

Processing

Heat Treatment: Hardening & Tempering
Finishing: No.1, 2B, BA, No.4
Cutting: Plasma, Laser, Waterjet
Testing: Hardness, PMI, Ultrasonic

SS 410 Plates Detailed Specifications

Property	Specification
Specifications	ASTM A240 / ASME SA240
Width	1000mm / 1219mm /1250mm / 1500mm / 2000mm
Length	2000 mm / 2440 mm / 2500 mm / 3000 mm / 6000 mm
Thickness	0.1mm to 12 mm Thk
Hardness	Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Finish	Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Form	Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle), Ring (Flange) etc.

SS 410 Plates Chemical Composition

Grade	C	Mn	Si	S	P	Cr	Ni	Fe
SS 410	0.08 – 0.15	0.0 – 1.50	0.0 – 1.00	0.0 – 0.02	0.0 – 0.04	11.50 – 13.50	0.0 – 0.75	Balance

SS 410 Plates Mechanical Properties

Element	Density	Tensile Strength	Yield Strength (0.2%Offset)	Elongation	Hardness
SS 410	7.8 g/cm3	65 (450) – 74 (510)	30 (205) – 42 (290)	20 – 34	82-96

SS 410 Plates Equivalent Grades

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	EN
SS 410	1.4006	S41000	SUS410	410S21	X12Cr13
