S355K2+N Plates

S355K2+N Plates
Material Grade: EN 10025-2 S355K2+N (High Toughness)
Impact Property: Guaranteed 40J Minimum at -20°C
Supply Condition: Normalized (+N) for Grain Refinement
Strength Level: 355 MPa Minimum Yield Strength
Mechanical Edge: Exceptional Resistance to Brittle Fracture
Fabrication Advantage: Superior Through-Thickness Performance
Thickness Range: 10 mm to 250 mm
Primary Industries: Earthmoving Machinery, Bridge Bearings, & Offshore
goldenislands.com.sa

S355K2+N Plates are elite high-strength structural steels engineered for applications where mechanical failure is not an option. While sharing the 355 MPa minimum yield strength common to the S355 family, the "K2" designation sets this material apart by offering the highest level of impact toughness. These plates are strictly tested to ensure a minimum energy absorption of 40 Joules at -20°C, providing a significant safety buffer over the J2 grade. The +N suffix confirms that the steel has been Normalized, a heat treatment that refines the grain structure to ensure that these superior mechanical properties are consistent throughout the entire thickness of the plate.

The technical superiority of EN 10025-2 S355K2+N makes it indispensable for critical structural components subjected to high dynamic loads and severe environmental stress. By combining enhanced fracture toughness with a stress-relieved, normalized microstructure, these plates offer exceptional resistance to fatigue and brittle cracking. This grade is the primary choice for heavy-duty earthmoving equipment, critical bridge joints, offshore platform components, and high-load crane booms. For fabricators, the normalized condition ensures excellent dimensional stability during heavy welding and precision cutting, making S355K2+N the definitive standard for high-integrity infrastructure and heavy engineering.



S355K2+N Plates Features

  • » Elite Impact Toughness (K2): Guaranteed minimum impact energy of 40 Joules at -20°C, offering the highest level of protection against brittle fracture in the S355 series.
  • » Normalized Microstructure (+N): Processed through thermal normalization to ensure a fine-grained, uniform structure that provides consistent mechanical performance across all plate dimensions.
  • » Exceptional Dynamic Load Resistance: Specifically engineered to withstand high-frequency vibrations and repetitive stress, making it ideal for heavy machinery and bridge components.
  • » Superior Through-Thickness Ductility: The normalized state minimizes internal inclusions and stresses, providing excellent Z-direction properties to resist lamellar tearing in critical welded joints.
  • » High Yield Strength (355 MPa): Maintains the robust structural integrity of high-tensile steel, allowing for significant weight savings in large-scale engineering projects.
  • » Excellent Weld Integrity: Despite its high toughness, the controlled chemistry ensures superb weldability with standard industrial methods, maintaining a strong heat-affected zone (HAZ).
  • » Maximum Dimensional Stability: Normalization relieves internal rolling stresses, ensuring the plate remains flat and true during heavy-duty plasma or laser cutting operations.
  • » Cold Forming Precision: The refined metallurgical structure allows for tight bending and forming without surface cracking, even in heavy-thickness sections used for crane booms.

S355K2+N Plates Specification

Standards

  • EN Standard: EN 10025-2
  • Grade: S355K2+N
  • Werkstoff No: 1.0596
  • Compliance: High-Toughness Structural

Chemistry

  • Carbon (C): 0.20% Max
  • Manganese (Mn): 1.60% Max
  • Silicon (Si): 0.55% Max
  • Phosphorus (P): 0.025% Max

Strength

  • Yield Strength: 355 MPa (Min)
  • Tensile Strength: 470 – 630 MPa
  • Elongation: 22% (Min)
  • Modulus: 210 GPa

High Toughness

  • Impact (K2): 40J @ -20°C (Min)
  • Supply State: Normalized (+N)
  • Deoxidation: Fully Killed
  • Grains: Fine-Grained Al-Killed

Dimensions

  • Thickness: 10 mm to 250 mm
  • Width: 1500 mm to 3500 mm
  • Length: 6000 mm to 12000 mm
  • Edge Finish: Machine Beveling Ready

Verification

  • MTC: EN 10204 3.1 / 3.2
  • NDT: UT (Ultrasonic) Level S1/S2
  • Z-Test: Optional Z15/Z25/Z35
  • Approval: CE / DNV / Lloyd’s

S355K2+N Plates Detailed Specifications

Property Specification
Item S355K2+N - Offshore & Structural Steel Plate
Thickness 5mm-150mm
Width 1000mm-4500mm
Length 3000mm-18000mm or as custom’s request
Material En 10025-2 Steel Plate, S355K2+N Steel Plate
Technique hot rolled
Standard EN 10025-2:2004

S355K2+N Plates Chemical Composition

Grade C Si Mn P S Cu CEV
S355K2+N 0.22 max. 0.55 max. 1.6 max. 0.03 max. 0.03 max. 0.55 max. 0.47 max.

S355K2+N Plates Mechanical Properties

Nominal thk (mm) to 3 3–100 100–150 150–250 250–400
Tensile strength (MPa) 510-680 470-630 450-600 450-600 450-600
Nominal thk (mm) to 16 16–40 40–63 63–80 80–100 100–150 150–200 200–250
Minimum yield strength (MPa) 355 345 335 325 315 295 285 275
Nominal thk (mm) to 1 1 – 1.5 1.5 – 2 2 – 2.5 2.5 – 3
A – Min. elongation Lo = 80 mm (%) parallel, 14 15 16 17 18

S355K2+N Plates Equivalent Grades

EN 10025-2 Steel Number DIN 17100 BS JIS
S355K2+N 1.0596 ST52-3N 50EE G3106 SM490
