Golden Steel Material is a premier Stainless Steel 347 Tubes Supplier in Saudi Arabia, offering high-performance piping solutions for the Kingdom’s critical high-temperature and high-pressure sectors. Our ASTM A312 TP347 tubes are stabilized with Columbium (Niobium), providing exceptional resistance to intergranular corrosion and chromium carbide precipitation when exposed to temperatures in the 427°C to 816°C range, common in Jubail’s petrochemical plants.
As a leading SS 347 Seamless Tubes stockist, we supply materials that offer slightly higher creep and stress rupture properties than Grade 321. These tubes are the definitive choice for radiant superheaters, boiler tubes, flare stacks, and heavy-wall refinery components in Yanbu, Dammam, and Riyadh. The addition of Columbium ensures that the material maintains its structural integrity and chemical stability even under the most severe thermal stresses found in Saudi Arabia's heavy power generation infrastructure.
We act as a trusted Stainless Steel 347 Tubes exporter in Saudi Arabia, ensuring all products meet ASME SA213 and SA312 standards. With competitive lead times and a robust inventory for major refinery turnarounds, we provide Saudi industrial contractors with durable 347 tubing solutions that maximize service life and minimize risk in volatile high-heat environments.
SS 347 Seamless Tube Supplier
SS 347 Welded / ERW Tube
SS 347 Large Diameter Tubes
| Features | Specifications |
|---|---|
| SS Tube Grade | TP 304/ SS 304, TP 304H/ SS 304H, TP 304L/ SS 304L, TP 304LN/ SS 304LN, TP 316/ SS 316, TP 316H/ SS 316H, TP 316L/ SS 316L, TP 316LN/ SS 316LN, TP 316Ti/ SS 316Ti, TP 309/ SS 309, TP 310/ SS 310, TP 317L/ SS 317L, TP 321/ SS 321, TP 347/ SS 347, TP 409/ SS 409, TP 410/ SS 410, TP 420/ SS 420, TP 430/ SS 430, TP 446/ SS 446, TP 202/ SS 202 etc. |
| Specification | ASTM A 269/A 213 / EN 10216-5 / NACE MR0175/PED 97/23 EC |
| Outside Diameter | 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock, OD Size Steel Tubes available Ex-stock |
| Thickness Range | 0.3mm – 50 mm, SCH 5, SCH 10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Type | Seamless / ERW / Welded / Fabricated / CDW |
| End | Plain End, Beveled End, Threaded |
| End Protection | Plastic Caps / Protective End Protectors |
| Outside Finish | 2B, No.4, No.1, No.8 Mirror Finish for Stainless Steel Pipes, Finish as per customer Requirements |
| Delivery Condition | Annealed and Pickled, Polished, Bright Annealed, Cold Drawn |
| Brand / Origin | European, Japanese, Korean, US, Russian, Indian, and Saudi Arabian Origin |
| Special Pipes | Stainless Steel 347 Fabricated Pipe (with radiography) |
| In Form of |
|
| In Length of | Single Random, Double Random, Standard & Cut length |
| Value Added Service |
|
| Test Certificate |
Manufacturer Test Certificate / Laboratory Test Certificate from Govt. Approved Lab. Under Third Party Inspection. Includes: Mill Test Certificates, EN 10204 3.1, Chemical Reports, Mechanical Reports, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, NABL Approved Lab Reports, Destructive Test Report, Non Destructive Test Reports. |
| Specialize |
|
| UNSPSC Code |
|
SS 347 Seamless Pipe
SS 347 Welded Pipe
SS 347 Tubing
Thick wall SS 347 tube
SS 347 Round Tube
Custom Stainless Steel 347 tube
| Nominal Pipe Size (inches) | Outside Diameter | Schedules (Wall Thickness & Weight) | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| mm | inches | 5S | 10S | 40S | 80S | |||||
| WT (mm) | kg/m | WT (mm) | kg/m | WT (mm) | kg/m | WT (mm) | kg/m | |||
| 1/8 | 10.3 | 0.405 | – | – | 1.25 | 0.28 | 1.73 | 0.37 | 2.42 | 0.47 |
| 1/4 | 13.7 | 0.540 | – | – | 1.66 | 0.49 | 2.24 | 0.63 | 3.03 | 0.80 |
| 3/8 | 17.2 | 0.675 | – | – | 1.66 | 0.63 | 2.32 | 0.85 | 3.20 | 1.10 |
| 1/2 | 21.3 | 0.840 | 1.65 | 0.81 | 2.11 | 1.00 | 2.77 | 1.27 | 3.74 | 1.62 |
| 3/4 | 26.7 | 1.050 | 1.65 | 1.02 | 2.11 | 1.28 | 2.87 | 1.68 | 3.92 | 2.20 |
| 1 | 33.4 | 1.315 | 1.65 | 1.30 | 2.77 | 2.09 | 3.38 | 2.50 | 4.55 | 3.24 |
| 1 1/4 | 42.2 | 1.660 | 1.65 | 1.66 | 2.77 | 2.69 | 3.56 | 3.39 | 4.86 | 4.47 |
| 1 1/2 | 48.3 | 1.900 | 1.65 | 1.91 | 2.77 | 3.11 | 3.69 | 4.06 | 5.08 | 5.41 |
| 2 | 60.3 | 2.375 | 1.65 | 2.40 | 2.77 | 3.93 | 3.92 | 5.45 | 5.54 | 7.49 |
| 2 1/2 | 73.0 | 2.875 | 2.11 | 3.69 | 3.05 | 5.26 | 5.16 | 8.64 | 7.01 | 11.4 |
| 3 | 88.9 | 3.500 | 2.11 | 4.52 | 3.05 | 6.46 | 5.49 | 11.3 | 7.62 | 15.3 |
| 4 | 114.3 | 4.500 | 2.11 | 5.84 | 3.05 | 8.37 | 6.02 | 16.1 | 8.56 | 22.3 |
| 6 | 168.3 | 6.625 | 2.77 | 11.3 | 3.41 | 13.9 | 7.12 | 28.3 | 10.98 | 42.6 |
| 8 | 219.1 | 8.625 | 2.77 | 14.8 | 3.76 | 20.0 | 8.18 | 42.5 | 12.70 | 64.6 |
| 12 | 323.9 | 12.750 | 3.97 | 31.3 | 4.58 | 36.1 | 9.53 | 73.9 | 12.70 | 97.4 |
| Grade | Limit | Fe | Cr | Ni | Mn | Si | P | C | S | Nb (Niobium) |
|---|---|---|---|---|---|---|---|---|---|---|
| AISI 347 | Min | Bal. | 17.0 | 9.0 | – | – | – | 0.040 | – | 8 x C |
| Max | – | 20.0 | 13.0 | 2.00 | 0.75 | 0.040 | 0.080 | 0.030 | 0.80 |
Physical Properties
| Property Type | Grade 347 | Grade 347H |
|---|---|---|
| Tensile Strength (MPa) | 515 – 690 (Min) | 515 – 740 (Min) |
| Yield Strength 0.2% Offset (MPa) | 215 – 260 (Min) | 215 – 260 (Min) |
| Elongation (% in 50mm) | 40 (Min) | 40 (Min) |
| Density / Weight (g/cm³) | 7.90 | 7.90 |
| Grade Series | Available Product Variants (Seamless & Welded) |
|---|---|
| General | Stainless Steel Pipe |
| 304 Series | Stainless Steel 304 Pipe & Tubes, SS 304 Seamless Pipe, SS 304 Seamless Tubes, SS 304 Welded Pipe, SS 304 Welded Tubes, Stainless Steel 304L Pipe & Tubes, SS 304L Seamless Pipe, SS 304L Seamless Tubes, SS 304L Welded Pipe, SS 304L Welded Tubes, Stainless Steel 304H Seamless Pipe & Tubes, SS 304H Welded Pipe & Tubes |
| 310 Series | SS 310 Seamless Pipe, SS 310 Seamless Tubes, SS 310 Welded Pipe, SS 310 Welded Tubes, Stainless Steel 310S Pipe & Tubes, SS 310S Seamless Pipe, SS 310S Seamless Tubes, SS 310S Welded Pipe, SS 310S Welded Tubes |
| 316 Series | Stainless Steel 316 Pipe & Tubes, SS 316 Seamless Pipe, SS 316 Seamless Tubes, SS 316 Welded Pipe, SS 316 Welded Tubes, Stainless Steel 316L Pipe & Tubes, SS 316L Seamless Pipe, SS 316L Seamless Tubes, SS 316L Welded Pipe, SS 316L Welded Tubes, SS 316H Pipes & Tubes |
| 317 Series | SS 317 Seamless Pipe, SS 317 Seamless Tubes, SS 317 Welded Pipe, SS 317 Welded Tubes, Stainless Steel 317L Pipe & Tubes, SS 317L Seamless Pipe, SS 317L Seamless Tubes, SS 317L Welded Pipe, SS 317L Welded Tubes |
| 321 Series | Stainless Steel 321 Pipe & Tubes, SS 321 Seamless Pipe, SS 321 Seamless Tubes, SS 321 Welded Pipe, SS 321 Welded Tubes, Stainless Steel 321H Pipe & Tubes, SS 321H Seamless Pipe & Tubes, SS 321H Welded Pipe & Tubes |
| 347 Series | Stainless Steel 347 Pipe & Tubes, SS 347 Seamless Pipe, SS 347 Seamless Tubes, SS 347 Welded Pipe, SS 347 Welded Tubes, Stainless Steel 347H Pipe & Tubes, SS 347H Seamless Pipe & Tubes, SS 347H Welded Pipe & Tubes |
| 400 Series | SS 410 Seamless Pipe, SS 410 Seamless Tubes, SS 410 Welded Pipe, SS 410 Welded Tubes, Stainless Steel 440C Pipe & Tubes, Stainless Steel 446 Pipe & Tubes, SS 446 Seamless Pipe, SS 446 Seamless Tubes, SS 446 Welded Pipe, SS 446 Welded Tubes |
| 904L Series | SS 904L Seamless Pipe, SS 904L Seamless Tubes, SS 904L Welded Pipe, SS 904L Welded Tubes |
