Golden Steel Material is a premier ISO-certified stockist based in Al Jubail. We supply high-performance pipes, fittings, valves, and flanges to the Oil & Gas and Industrial sectors across Saudi Arabia and the GCC.
Call Us
Send Email
Location
Welcome to Golden Steel Material Let’s Talk
Golden Steel Material is a premier Stainless Steel 316H Tubes Supplier in Saudi Arabia, providing specialized high-temperature solutions for power plants, refineries, and chemical processing facilities. Our ASTM A312 TP316H tubes are engineered with a controlled carbon content (0.04% to 0.10%), which significantly enhances creep strength and tensile properties at temperatures exceeding 500°C in the demanding environments of Jubail and Yanbu.
As a leading SS 316H Seamless Tubes stockist, we supply tubing that offers superior thermal stability and resistance to sensitization compared to low-carbon variants in high-heat applications. Our 316H boiler and superheater tubes are critical for steam generation, furnace components, and heat exchangers in Riyadh and Jeddah, ensuring structural integrity where standard stainless grades might suffer from long-term mechanical failure.
We act as a trusted Stainless Steel 316H Tubes exporter in Saudi Arabia, delivering fully certified materials that comply with ASME SA213 and SA312 standards. With competitive pricing and massive local inventory for emergency maintenance shutdowns, we support Saudi industrial contractors with high-performance 316H tubing designed to withstand the most extreme thermal cycling and high-pressure service conditions.
SS 316H Seamless Tube Supplier
SS 316H Welded / ERW Tube
SS 316H Large Diameter Tubes
| Features | Specifications |
|---|---|
| SS Tube Grade | TP 304/ SS 304, TP 304H/ SS 304H, TP 304L/ SS 304L, TP 304LN/ SS 304LN, TP 316/ SS 316, TP 316H/ SS 316H, TP 316L/ SS 316L, TP 316LN/ SS 316LN, TP 316Ti/ SS 316Ti, TP 309/ SS 309, TP 310/ SS 310, TP 317L/ SS 317L, TP 321/ SS 321, TP 347/ SS 347, TP 409/ SS 409, TP 410/ SS 410, TP 420/ SS 420, TP 430/ SS 430, TP 446/ SS 446, TP 202/ SS 202 etc. |
| Specification | ASTM A 269/A 213 / EN 10216-5 / NACE MR0175/PED 97/23 EC |
| Outside Diameter | 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock, OD Size Steel Tubes available Ex-stock |
| Thickness Range | 0.3mm – 50 mm, SCH 5, SCH 10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Type | Seamless / ERW / Welded / Fabricated / CDW |
| End | Plain End, Beveled End, Threaded |
| End Protection | Plastic Caps / Protective End Protectors |
| Outside Finish | 2B, No.4, No.1, No.8 Mirror Finish for Stainless Steel Pipes, Finish as per customer Requirements |
| Delivery Condition | Annealed and Pickled, Polished, Bright Annealed, Cold Drawn |
| Brand / Origin | European, Japanese, Korean, US, Russian, Indian, and Saudi Arabian Origin |
| Special Pipes | Stainless Steel 316H Fabricated Pipe (with radiography) |
| In Form of |
|
| In Length of | Single Random, Double Random, Standard & Cut length |
| Value Added Service |
|
| Test Certificate |
Manufacturer Test Certificate / Laboratory Test Certificate from Govt. Approved Lab. Under Third Party Inspection. Includes: Mill Test Certificates, EN 10204 3.1, Chemical Reports, Mechanical Reports, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, NABL Approved Lab Reports, Destructive Test Report, Non Destructive Test Reports. |
| Specialize |
|
| UNSPSC Code |
|
SS 316H Seamless Pipe
SS 316H Welded Pipe
SS 316H Tubing
Thick wall SS 316H tube
SS 316H Round Tube
Custom Stainless Steel 316H tube
| Pipe/ Tube Type | NB Sizes | Sch 5 | Sch 10 | Sch 40 | Sch 80 | Sch 160 |
|---|---|---|---|---|---|---|
| Stainless Steel 316H Pipe / Tubes | 1/2 | - | ||||
| Stainless Steel 316H Pipe / Tubes | 3/4 | - | ||||
| Stainless Steel 316H Pipe / Tubes | 1 | - | ||||
| Stainless Steel 316H Pipe / Tubes | 1.25 | |||||
| Stainless Steel 316H Pipe / Tubes | 1.5 | |||||
| Stainless Steel 316H Pipe / Tubes | 2 | |||||
| Stainless Steel 316H Pipe / Tubes | 2.5 | |||||
| Stainless Steel 316H Pipe / Tubes | 3 | |||||
| Stainless Steel 316H Pipe / Tubes | 3.5 | |||||
| Stainless Steel 316H Pipe / Tubes | 4 | |||||
| Stainless Steel 316H Pipe / Tubes | 5 | |||||
| Stainless Steel 316H Pipe / Tubes | 6 | |||||
| Stainless Steel 316H Pipe / Tubes | 8 | |||||
| Stainless Steel 316H Pipe / Tubes | 10 | |||||
| Stainless Steel 316H Pipe / Tubes | 12 | |||||
| Stainless Steel 316H Pipe / Tubes | 14 | |||||
| Stainless Steel 316H Pipe / Tubes | 16 | |||||
| Stainless Steel 316H Pipe / Tubes | 18 | |||||
| Stainless Steel 316H Pipe / Tubes | 20 | |||||
| Stainless Steel 316H Pipe / Tubes | 22 | - | ||||
| Stainless Steel 316H Pipe / Tubes | 24 | - |
| Grade | Limit | C | Mn | Si | P | S | Cr | Mo | Ni | N |
|---|---|---|---|---|---|---|---|---|---|---|
| 316 | Min | – | – | – | 0 | – | 16.0 | 2.00 | 10.0 | – |
| Max | 0.08 | 2.0 | 0.75 | 0.045 | 0.03 | 18.0 | 3.00 | 14.0 | 0.10 | |
| 316L | Min | – | – | – | – | – | 16.0 | 2.00 | 10.0 | – |
| Max | 0.03 | 2.0 | 0.75 | 0.045 | 0.03 | 18.0 | 3.00 | 14.0 | 0.10 | |
| 316H | Min | 0.04 | 0.04 | 0 | – | – | 16.0 | 2.00 | 10.0 | – |
| Max | 0.10 | 0.10 | 0.75 | 0.045 | 0.03 | 18.0 | 3.00 | 14.0 | – |
Physical Properties
| Grade | Tensile Strength (MPa) Min | Yield Strength 0.2% Proof (MPa) Min | Elongation (% in 50mm) Min | Hardness (Max) | |
|---|---|---|---|---|---|
| Rockwell B (HR B) | Brinell (HB) | ||||
| AISI 316 | 515 | 205 | 40 | 95 | 217 |
| AISI 316L | 485 | 170 | 40 | 95 | 217 |
| AISI 316H | 515 | 205 | 40 | 95 | 217 |
| Nominal Pipe Size (inches) | Outside Diameter | Schedules (Wall Thickness & Weight) | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| mm | inches | 5S | 10S | 40S | 80S | |||||
| WT (mm) | kg/m | WT (mm) | kg/m | WT (mm) | kg/m | WT (mm) | kg/m | |||
| 1/8 | 10.3 | 0.405 | – | – | 1.25 | 0.28 | 1.73 | 0.37 | 2.42 | 0.47 |
| 1/4 | 13.7 | 0.540 | – | – | 1.66 | 0.49 | 2.24 | 0.63 | 3.03 | 0.80 |
| 3/8 | 17.2 | 0.675 | – | – | 1.66 | 0.63 | 2.32 | 0.85 | 3.20 | 1.10 |
| 1/2 | 21.3 | 0.840 | 1.65 | 0.81 | 2.11 | 1.00 | 2.77 | 1.27 | 3.74 | 1.62 |
| 3/4 | 26.7 | 1.050 | 1.65 | 1.02 | 2.11 | 1.28 | 2.87 | 1.68 | 3.92 | 2.20 |
| 1 | 33.4 | 1.315 | 1.65 | 1.30 | 2.77 | 2.09 | 3.38 | 2.50 | 4.55 | 3.24 |
| 1 1/4 | 42.2 | 1.660 | 1.65 | 1.66 | 2.77 | 2.69 | 3.56 | 3.39 | 4.86 | 4.47 |
| 1 1/2 | 48.3 | 1.900 | 1.65 | 1.91 | 2.77 | 3.11 | 3.69 | 4.06 | 5.08 | 5.41 |
| 2 | 60.3 | 2.375 | 1.65 | 2.40 | 2.77 | 3.93 | 3.92 | 5.45 | 5.54 | 7.49 |
| 2 1/2 | 73.0 | 2.875 | 2.11 | 3.69 | 3.05 | 5.26 | 5.16 | 8.64 | 7.01 | 11.4 |
| 3 | 88.9 | 3.500 | 2.11 | 4.52 | 3.05 | 6.46 | 5.49 | 11.3 | 7.62 | 15.3 |
| 4 | 114.3 | 4.500 | 2.11 | 5.84 | 3.05 | 8.37 | 6.02 | 16.1 | 8.56 | 22.3 |
| 6 | 168.3 | 6.625 | 2.77 | 11.3 | 3.41 | 13.9 | 7.12 | 28.3 | 10.98 | 42.6 |
| 8 | 219.1 | 8.625 | 2.77 | 14.8 | 3.76 | 20.0 | 8.18 | 42.5 | 12.70 | 64.6 |
| 12 | 323.9 | 12.750 | 3.97 | 31.3 | 4.58 | 36.1 | 9.53 | 73.9 | 12.70 | 97.4 |
